Modern equilateral tile shapes
EQ range
This simple set of tiles provides a modern geometric tiling option for those looking to explore a new aesthetic. The EQ tile range features three unique shapes that you can arrange to create striking repeating patterns, making them perfect for interior and exterior applications.
Shapes
185 x 185 mm
Hexagon
105 x 182 mm
Diamond
104 x 89 mm
Triangle
Due to their dimensions, these tile shapes fit neatly with each other but are incompatible with our core heritage range when creating field patterns. However, border designs constructed with our core range can frame the EQ patterns as they share the same thickness.
EQ tiles feature chamfered edges and can be supplied loose or pre-assembled onto sheets with minimal grout lines. They're available in seven colour options, carefully matched to tones in our core range.
Discover an evolving selection of EQ pattern layouts in our catalogue and explore the creative potential of these geometric shapes.
Technical specifications
| Feature | Details |
|---|---|
| Manufacturer | Original Style Ltd, Exeter, Devon, England |
| Conformity | Complies with European Directive 89/106/CEE |
| Standards | EN 14411 – Group BIb, dry-pressed vitrified ceramic tiles |
| Water absorption | Low: 0.5% – 3% |
| Dimensions and surface quality | Meets BS EN ISO 10545-2 standards |
| Size tolerances | For tile sides between 7-15 cm: ±0.9 mm. For tile sides ≥15 cm: ±0.6% (up to ±2.0 mm max) |
| Surface hardness | Mohs scale rating: 7 (excellent resistance to scratches) |
| Chemical resistance | Conforms to BS EN ISO 10545-13: UHA, ULA, UA |
| Thermal shock resistance | Conforms to BS EN ISO 10545-9 |
| Impact resistance | Conforms to BS EN ISO 10545-5 |
| Breaking strength | >1100 Newtons (BS EN ISO 10545-4) |
